Product Description:

The large-scale disc pelletizing machine developed by Henan Zhengzhou Mining Machinery Co., Ltd. is an excellent technological product. It has features of smooth operation, high pelletizing quality, low energy consumption and easy maintenance, and has excellent high reliability. Compared with the traditional ball making machine, it successfully avoids the instability and vibration problems caused by the cantilever shaft support structure. The innovative design of this product provides a reliable and efficient solution for phosphogypsum, cement retarder, steel pelletizing and other industries, making it the preferred equipment in the field of pellet manufacturing.

Features:

1. Large-diameter slewing bearings and plane bearings are used to ensure that the pelletizing disc is stable and vibration-free during operation, thereby ensuring high pelletizing quality.
2. The pelletizing output is large. The qualified ball output of the 6-meter pelletizing machine is maintained at 60-90 tons per hour, and the output of the 7.5-meter pelletizing machine is maintained at 120-160 tons per hour.
3. Low energy consumption, the energy consumption per ton of balls is 0.7-0.8 of that of traditional pelletizers, enabling enterprises to save energy and reduce consumption in the production process, and obtain considerable economic and social benefits.
4. The maintenance is easy, and there is almost no daily maintenance work during the use of the equipment. The maintenance parts of the 7.5-meter pelletizer are about 4.3 tons. Compared with traditional pelletizing machines, the maintenance amount is greatly reduced and there are fewer failures. Even the time required to replace the core components is very short, usually in about three to five days.

Application:

Applicable materials: phosphogypsum, cement retarder, iron powder, steel ball, etc.
Application field: Mainly used for granulation of phosphogypsum, cement retarder pellets and steel pellets.

Technical Parameters:

Model	Dia(mm)	Height(mm)	Slope(°)	Speed(r/min)	Main Drive Motor Power(kW)	Scraper Motor Power(kW)	Weight (t)
PQ50	5000	600	43~53°	6~9	75	5.5×2	20
PQ55	5500	650	43~53°	5.7~8.5	90	5.5×2	33.5
PQ60	6000	650	43~53°	5.7~8.5	110	5.5×2	36.5
PQ70	7000	650	43~53°	5.1~7.9	185	5.5×3	51
PQ75	7500	650	43~53°	5.1~7.9	200	5.5×3	55.6

Certifications:

Henan ZK Corp has been honored as a high-tech, innovative, technological, specialized and special new enterprise successively, and has 22 various honorary certificates such as “Specialized, Refined, and Innovative”, CE certification.

What We Do

1. Building materials process for:
Light Expanded Aggregate (LECA), Ceramsite Sand, Oil Fracturing Proppant, Refractory, Powder, Lime, Cement Production etc.;
2. Metallurgical process for:
Magnesium Metal Production Process (Calcination, Pelletizing, Reduction, and Refining);
3. Calcination/Sintering Process for :
Dolomite, Limestone, Magnesite, Bauxite, Kaolin, Filter cake from Sugar Plant and Paper Plant etc….
4. Environmental protection process for:
Hazardous Solid and Waste Solid Treatment (sludge, shale, chrome mud, red mud, fly ash, coal gangue, etc.), Dedusting and Flue Gas Purification etc.;
