Small Scale Waste Incinerator Solid Waste Incinerator Machine
Rotary Kiln Incinerator Introduction:
Rotary incinerator is a widely used incineration equipment in the
field of international industrial waste treatment, its market share
in the field of industrial waste incineration is really high, As a
specific area for burning hazardous wastes , the rotary incinerator
has wide adaptability to complex industrial waste and medical
waste, and it’s stable and convenient to operate, of course, the
equipment maintenance is simple, and so on. Therefore, it is the
most widely used in the field of international hazardous waste
incineration. It is a reliable and effective means to realize the
harmless, reduction and recycling of wastes.
Rotary Kiln Incinerator Application:
It is widely used in the field of industrial waste, medical waste,
municipal solid waste, and so on.
Rotary Kiln Incinerator Applicable material:
Hazardous waste, sludge waste, medical waste, steel mill flue ash,
sugar residue, paper mill residue, aluminum slag, pharmaceutical
filter residue, oily sludge, electroplating sludge, paint residue,
industrial waste, PVC material, municipal waste, domestic garbage,
batteries, tires, leather sludge, and so on.
Rotary kiln for Waste incineration (Rotary Kiln Incinerator) is
usually used to burn pretreated and homogenized waste that requires
size reduction, shredding, and manual sorting. The system consists
of a burning layer of waste in a rotating cylinder. Rotary Kiln
Incinerator is a widely used incineration equipment in the field of
international industrial waste treatment, its market share in the
field of industrial waste incineration is really high.
Specifications:
| Hazardous waste rotary kiln for waste incinerationφ2.6m*13.2
technical parameter. |
| Inner diameter of shell 2600mm | Shell length 13200mm |
| Downstream arrangement, that is, the direction of material flow is
consistent with the direction of smoke flow, the angle of the kiln
body is 1.5 degrees. |
| Variable frequency speed control of rotary kiln | 0.1-2.2r/min |
| Drive mode | Single side gear drive |
| Main Motor | 30kw |
| Kiln temperature:850-1200 degree | Surface temperature of kiln shell: 180 degree |
| Expansion mode | Linear free expansion at both ends |
| Total equipment weight | approx. 54.5t |
| ★Customized waste incineration rotary kiln can be provided
according to the customers' different industries |
Rotary Kiln Incinerator Structure:
1.There are 2 to 3 fulcrums on Rotary Kiln Incinerator. It is easy
to ensure the contact surface of rollers and kiln tires parallel to
the cylinder axis during installing;
2.There are specific gap between the tire and cylinder. It
strengthens the cylinder by confining tires after thermal
expansion;
3.The supports use rolling bearing which simplified bearing
structure. It reduces energy losses during Rotary Kiln Incinerator
operation and makes Rotary Kiln Incinerator easier to maintain and
repair;
Rotary Kiln Incinerator Advantages:
1. Combining patented technology: The traditional two combustion
chamber is evolved into a two combustion furnace. The burnout rate
of ash is improved. The combustion efficiency of rRotary Kiln
Incinerator is improved. At the same time, it has the functions of
slag discharging at normal temperature, crushing slag and sealing,
locking air, etc.
2. High heat utilization rate: The material was churned forward.
The three heat transfer modes coexist in one furnace
3. Adaptability to incineration: Solid waste ,liquid, colloid, and
gas can be incinerated simultaneously
