Large Scale Ball Mill Aluminum Powder With 0.8-230 TPH
Ball Mill Introduction:
Ball mill is the key equipment for recrushing the materials after
they are primarily crushed. Ball mill is mainly used for grinding
in mining (metallic minerals and non-metallic minerals), cement,
refractories, chemical, power plant, aluminum ,building material,
glass, ceramic, steel slag and fly ash, ect. The feed size to ball
mill shall be smaller than 25mm, the output size can be adjusted by
revising steel balls ratio.
Specifications of Mineral Ball Mill:
| Model | Drum Size (m) | Speed (r/min) | Ball Weigh(t) | Feed Size (mm) | Output Size (mm) | Capacity (t/h) | Power (kW) |
| MQZ1224 | 1.2X2.4 | 31 | 4.8 | 0-20 | 0.07-0.6 | 0.4-6.8 | 37 |
| MQZ1245 | 1.2X4.5 | 31 | 5.2 | 0-20 | 0.07-0.6 | 1.6-12 | 45 |
| MQZ1530 | 1.5X3.0 | 27.5 | 8.1 | 0-25 | 0.07-0.4 | 2.9-16.5 | 65 |
| MQZ1557 | 1.5X5.7 | 29.2 | 15 | 0-25 | 0.07-0.4 | 4-25 | 95 |
| MQZ1645 | 1.6X4.5 | 27.5 | 14 | 0-25 | 0.07-0.4 | 4-24 | 95 |
| MQZ1836 | 1.8X3.6 | 23.9 | 11 | 0-25 | 0.07-0.4 | 8-40 | 132 |
| MQZ1864 | 1.6X6.4 | 23.9 | 18.5 | 0-25 | 0.07-0.4 | 8-60 | 155 |
| MQZ2130 | 2.1X3.0 | 23.8 | 19.8 | 0-25 | 0.07-0.4 | 6.5-36 | 155 |
| MQZ2136 | 2.1X3.6 | 23.8 | 27 | 0-25 | 0.07-0.4 | 8-61 | 155 |
| MQZ2265 | 2.2X6.5 | 21.6 | 28 | 0-25 | 0.07-0.4 | 8-35 | 210 |
| MQZ2430 | 2.4X3.0 | 22 | 22.5 | 0-25 | 0.07-0.4 | 7-92 | 210 |
| MQZ2436 | 2.4X3.6 | 22 | 28 | 0-25 | 0.07-0.4 | 7-95 | 210 |
| MQZ2465 | 2.4X6.5 | 22 | 36 | 0-25 | 0.07-0.4 | 7-110 | 260 |
| MQZ2736 | 2.7X3.6 | 21.9 | 39 | 0-25 | 0.07-0.4 | 13-140 | 310 |
| MQZ2745 | 2.7X4.5 | 21.9 | 43 | 0-25 | 0.07-0.4 | 13-150 | 320 |
| MQZ2836 | 2.8X3.6 | 20 | 42 | 0-25 | 0.07-0.4 | 15-140 | 310 |
| MQZ3060 | 3.0X6.0 | 19 | 70 | 0-25 | 0.07-0.4 | 100-145 | 630 |
| MQZ3245 | 3.2X4.5 | 18.6 | 65 | 0-25 | 0.07-0.4 | 100-145 | 630 |
| MQZ3260 | 3.2X6.0 | 18.6 | 86 | 0-25 | 0.07-0.4 | 120-150 | 800 |
| MQZ3645 | 3.6X4.5 | 17.8 | 90 | 0-25 | 0.07-0.4 | 120-220 | 1000 |
| MQZ3660 | 3.6X6.0 | 17.8 | 120 | 0-25 | 0.07-0.4 | 50-230 | 1250 |
Working Principle
1. This ball mill, a horizontal type and tubular running device,
has two chamber. This machine is grid type. The material enters
first warehouse spirally and evenly along the input material hollow
axis by input material device.
2. In this chamber, there is a ladder scaleboard or ripple
scaleboard, and different specification steel balls. When shell
rotates and it produces centrifugal force. At this time, steel
balls will be carried to certain height and falls down to make the
material heavy impact and grinded.
3. After being grinded coarsely in the first chamber, material
enters second chamber for regrinding with the steel ball and
scaleboard. At the end, the powder is discharged by output material
board and the final products are completed.
