Screw Shaftless Conveyor Cement / Screw Conveyor Cement
Manufacturers
Screw Shaftless Conveyor Introduction:
Shaft-less screw conveyor is a fairly recent development in screw conveyor design and is
growing in popularity because it is the perfect solution for many
bulk solids handling applications. The shaft-less screw conveyor is
the solution for conveying many difficult bulk solids. In fact, the
shaft-less conveyor was so successful in the Environmental
industry, that its use has been promoted in many other industries
such as chemical, food, and minerals processing.
Shaft-less Screw Conveyor Application:
It is widely used in building material, metallurgy, chemical
industry, electric power, coal, machinery, light industry, food and
food industry, suitable for conveying powder, granule, small block
material, such as cement, coal, food, chemical fertilizer, ash,
sand, coke, etc.
Screw Conveyor Structure:
A shaft-less conveyor is designed to be supported by a liner that
conforms to the radius of the trough. The weight of the shaft-less
spiral is distributed over the full length of the spiral on the
liner. The drive is connected to one end of the spiral by means of
a flanged and bolted drive shaft and spiral end plate, while the
tail end of the spiral is not connected and is allowed to rotate
freely. If your process consists of bulk solids with high moisture
content, then the shaft-less screw conveyor is a perfect solution.
Technical Parameters:
| Revolution(r/min) | GX-Type Srew Conveyor |
| GX150 | GX200 | GX250 | GX300 | GX400 | GX500 | GX600 |
| Output(m³/h) |
| 20 | 0.9 | 2.1 | 4.1 | 7.1 | 16.8 | 32.9 | 56.9 |
| 30 | 1.3 | 3.2 | 6.2 | 10.7 | 25.3 | 49.4 | 85.3 |
| 35 | 1.5 | 3.7 | 7.2 | 12.4 | 29.5 | 57.6 | 99.5 |
| 45 | 2 | 4.7 | 9.3 | 16 | 37.9 | 74 | 127.9 |
| 60 | 2.6 | 6.3 | 12.3 | 21.3 | 50.5 | 98.7 | 170.6 |
| 75 | 3.3 | 7.6 | 15.4 | 26.6 | 63.2 | 123.3 | 213.2 |
| 90 | 4 | 9.5 | 18.5 | 32 | 75.8 | 148 | 255.9 |
| LS-type screw conveyor |
| Model And Spec | Dia (mm) | Pitch(mm) | Top Rev(r/min) | Top Output(m³/h) |
| Fill Coefficient |
| Φ=0.45 | Φ=0.33 | Φ=0.15 |
| LS100 | 100 | 100 | 140 | 3 | 2.2 | 1 |
| LS125 | 125 | 125 | 125 | 5.2 | 3.8 | 1.7 |
| LS160 | 160 | 160 | 112 | 9.7 | 7.1 | 3.2 |
| LS200 | 200 | 200 | 100 | 16.9 | 12.4 | 5.6 |
| LS250 | 250 | 260 | 90 | 29.7 | 21.8 | 9.9 |
| LS315 | 315 | 315 | 80 | 52.9 | 38.8 | 17.6 |
| LS400 | 400 | 355 | 71 | 85.3 | 62.5 | 28.2 |
| LS500 | 500 | 400 | 63 | 133.2 | 97.7 | 44.4 |
| LS630 | 630 | 450 | 50 | 188.9 | 138.5 | 63 |
| LS800 | 800 | 500 | 40 | 270.7 | 198.5 | 70.2 |
| LS1000 | 1000 | 560 | 32 | 379 | 277.9 | 126.3 |
| LS1250 | 1250 | 630 | 25 | 520.5 | 381.7 | 173.5 |
Our service: Training & Service
Pre-sale services: enthusiasm
We provide you with the prophase plan, process flow design and
manufacturer equipment,
according to your special demand.
Sale services: servant
Send technicians to the jobsite for guiding the installation and
adjustment, training operators
and finishing the check and accept together with you.
After-sale services: faithfulness
To establish long term friendship, we will regularly pay return
visit to customers.
In addition, we provide one-year warrantee to make sure your
machine runs consistently. We always keep certain inventory level
of spare parts, which means the replacements can be shipped to you
right away.
Welcome to visit our company and workshop, we sincerely look
forward to cooperating with you. We will provide you with the most
suitable products with the reasonable price.
