High Efficiency Manufacturer Vertical Industrial Cyclone Dust
Collector Price
Cyclone Dust Collector Introduction:
XFCC series cyclone dust collector also called the centrifugal dust
collector, it is mainly used for removal of the dust of the
industrial waste gas with high density non-fabrous and
cohesiveness. It is used in ventilation dust removal and material
recycling system of mining, metallurgy, refractory, coal, chemical
and electric power industries, especially suitable for the initial
purification for high temperature flue gas.
Application of Woodworking Cyclone dust collector:
It is used in ventilation dust removal and material recycling
system of mining, metallurgy, refractory, coal, chemical and
electric power industries,
Cyclone Seperator Coarse Particles Structure:
XFCC cyclone dust collector is mainly composed of inner cylinder,
cylinder, cone tube, spiral case, etc.
Dust Collector Cyclone,Industrial Cyclone Dust Collector Advantages
As Followings:
1. Suitable for purification the dust with big density, and
particle size above 5 micron; not suitable for purification the
dust with strong cohesiveness.
2. No moving parts, easy to management and maintenance.
3. Under the same air volume processing, it small volume, simple
structure and low cost.
4. Many set machines work together in parallel with same air volume
processing, small volume, simple structure and low cost.
5. It can be resisted 400℃ high temperature, if adopts special high
temperature resistance material, it will resist higher temperature
than 400℃.
Cyclone Dust Collector Specifications:
| Specification | XD-Ⅱ-0.5 | XD-Ⅱ-1 | XD-Ⅱ-2 | XD-Ⅱ-4 | XD-Ⅱ-6 | XD-Ⅱ-10 | XD-Ⅱ-20 | XD-Ⅱ-35 |
| Boiler(t/h) | 0.5 | 1 | 2 | 4 | 6 | 10 | 20 | 35 |
| Exhaust Gas Volume (m3/h) | 1500 | 3000 | 6000 | 12000 | 18000 | 30000 | 60000 | 105000 |
| Collection efficiency(%) | ＞95 |
| Pressure drop(Pa) | ＜900 |
| Cut diameter | 3.05 |
| Weight | 310 | 570 | 960 | 1900 | 2910 | 6100 | 11750 | 20300 |
Cyclone dust collector has simple structure, no moving parts, no
special auxiliary equipment, small footprint, less investment in
manufacturing and installation.
The operation and maintenance of cyclone dust remover is simple,
and the power consumption in the pressure loss is small, the
operation and maintenance costs are low, and the dust with greater
than 10 mu m has a higher separation efficiency.
