Sludge Rotary Dryer Machine for Drying Slag, Coal, Slime
Rotary Dryer is widely used in the field of building materials, metallurgies,
chemical industry, cement and so on. It can dry slag, coal powder,
mining powder, clay, sand, limestone and so on. It is made into
rotary body, lifting blade, driving device, supporting device etc.
The dryer has advantages of reasonable structure, high efficiency,
low energy consumption and convenient for transportation. We supply the following dryer: wet material rotary dryer, sand
dryer, sawdust dryer, coal dryer, coal slime dryer, bentonite
dryer, ore concentrate dryer, wood chip dryer, cassava dryer,
gypsum dryer, cow dung dryer
Rotary Dryers Characteristics :
1. The internal adopts assembled structure which has improved the
accuracy of the equipment and it is easy to transport and install.
2. According to the characteristics of different fertilizers ,we
have arranged the second granulation zone reasonably so as to
improve the granulation effect .
3. Adopts assembled hoist board so as to exchange heat fully and
lower the energy consumption .
4. Temperature induction monitor ,uniform vibration and airproof
setting , which improve performance and productivity efficiently .
5. The assorted combustion furnace is a type of energy efficient
and has the characteristics of smaller area , easy regulation and
equipped with greenhouse
Application of Rotary Dryer
1. The rotary drum dryer made in our factory is mainly used for
chemical, mining, metallurgy industry, like mineral, slag, coal,
metal powder, clay, kieselguhr, kaolin, sand, lignite, slica
sand...
2. The rotary drum dryer can used for agriculture and fertilizer
industry, like straw, stalk, leaves, starch pulp, dregs of
decoction, pomace, bagasse, slurry, organic fertilizer, inorganic
fertilizer and others.
3. It also can used for drying the special materials, such as all
kinds of crystalline, argil, magnetic powder, inorganic mud, lime
slurry, aluminum mud, mineral mud and others.
Advantages of rotary dryer:
The dryer has advantages of reasonable structure, high efficiency,
low energy consumption and convenient transportation.
Performance Characteristics of Rotary Dryer:This series drier is
used for drying materials with humidity or granularity in
the industries of mineral dressing, building material, metallurgy
and chemical. Rotating dryer can be used for drying many kinds of
materials and with convenient and reliable operation; therefore, it
has been widely used.
Specification of rotary dryer:
| specification | cylinder | Capacity(t/h) | motor | Power(kw) | reducer |
| D(mm) | L(mm) | Slope(°) | Speed(rpm) | model |
| 1212 | 1200 | 12000 | 1.8 | 5 | 2-5 | Y160LM-6 | 11 | ZQ500 |
| 1515 | 1500 | 15000 | 1.8 | 4.28 | 4-5 | Y160L-6 | 18.5 | ZQ650 |
| 1818 | 1800 | 18000 | 1.8 | 5 | 6-8 | Y200LI-6 | 22 | ZA650 |
| 2020 | 2000 | 20000 | 2.0 | 3.28 | 7-10 | Y200L2-6 | 30 | ZQ650 |
| 2222 | 2200 | 22000 | 1.8 | 2.8 | 9-14 | Y250M-6 | 45 | ZQ650 |
| 2424 | 2400 | 24000 | 2.5 | 2.82 | 14-16 | Y280S-6 | 55 | ZQ750 |
| 2626 | 2600 | 26000 | 2.5 | 2.58 | 16-18 | Y280M-6 | 75 | ZQ850 |
| 2828 | 2800 | 28000 | 2.5 | 2.55 | 20-22 | Y315S-6 | 90 | ZL115 |
| 3030 | 3000 | 30000 | 2.5 | 2.69 | 22-24 | Y315L1-6 | 132 | ZL130 |
| 3232 | 3200 | 32000 | 2.5 | 2.6 | 24-26 | Y315M-4 | 200 | ZSY450 |
| 3434 | 3400 | 34000 | 2.5 | 2.51 | 26-28 | Y315L2-4 | 315 | ZL130 |
| 3634 | 3600 | 36000 | 2.5 | 2.51 | 30-40 | Y315L2-4 | 315 | ZL130 |
| 4040 | 4000 | 40000 | 2.5 | 2.09 | 40-45 | YKK4003-4 | 400 | ZSY630 |
| 4242 | 4200 | 42000 | 2.5 | 2.09 | 45-46 | YKK4005-4 | 400 | ZSY630 |
